ThermaCote Original (Bright White)

ThermaCote is a high-performance thermal barrier that offers superior corrosion protection for commercial, residential, exterior, and interior applications. The advanced ceramic technology conserves energy, looks just like flat latex paint when dry, and has ultra-low VOCs at 5.3 G/L.

ThermaCote spray-applied thermal barrier coating is Certified Green to California’s standard (DHS 01350) for indoor air quality in classrooms and offices, an ENERGY STAR qualified product, and is also a CRRC (Cool Roof Rating Council) “Rated” product. With built-in corrosion protection, ThermaCote is the perfect primer or topcoat on new or existing sheetrock, wood, glass, plastic, concrete or steel projects, and helps seal the envelope of any structure. A UL® Classified product with a 0-Flame spread, ThermaCote is the professional's choice.

Key Characteristics

Breathable vapor barrier, reduces condensation, low shrinkage due to high volume of solids (12 wmt = 10dmt), high solar reflectance, high emittance, low dry fall rate (5–10 feet, depending on temperature and humidity), lightweight (5 pounds/gallon, <2.27 kilos per 3.78 liters), wide range of application (50f– 300f), reduces expansion and contraction, max white brightness.

With ThermaCote

87.5°

Without ThermaCote

135.5°



what is thermacote?

ThermaCote

product downloads

ThermaCote

Product Data Sheet

ThermaCote Colors

Spec Sheet

ThermaCote

Application Guide

ThermaCote

MSDS

ThermaCote

Sustainability

Click to download the ThermaCote product pdf spec sheets and Adobe Reader.

application and installation

Ratings

ThermaCote Product Application

ThermaCote is a single stage coating designed for application via heavy-duty airless sprayer capable of maintaining an output of 2 GPM (8 LPM) with a 3/8" pressure-rated hose. Brushing and rolling is not recommended, but may be used in smaller, hard to reach areas. Other equipment includes a mixing paddle, variable speed drill, and safety equipment (goggles, respirator, etc.).

ThermaCote will adhere to almost any surface which is properly prepared and thoroughly cleaned, dry, and free from all dirt, debris, rust, grease, oil, and any other foreign substance. Do not open product until ready to apply, and plan to mix and use the entire contents of the opened container in one application. Mix ThermaCote using a mixing paddle and drill until you have a smooth, lump-free homogeneous liquid (2 minutes or less), and apply in coats of a 10 to 25 wet mil thickness (WMT) dependent upon the application. Coverage should average 50 square feet per gallon at 20 mils thickness on flat surfaces, and approximately 80 square feet a gallon on smooth metal surfaces at 13 WMT. Use warm, soapy water for cleanup of tools, equipment, spills and drips.

Download ThermaCote

Application Guide

Application Guide

The instructions above give a brief overview of how to properly apply ThermaCote. For the complete guide to surface preparation, mixing, spraying, and clean up, download the ThermaCote Application Guide.

ratings and accreditations

> CLICK ON THE LOGOS TO SEE DETAILED INFORMATION

ON OUR RATINGS AND ACCREDITATIONS

ThermaCote Ratings and Accreditations

ThermaCote is proud of the extensive certifications and accreditations that have been completed during our long history of product development and testing. Our ongoing mission is to continue to enhance and perfect our thermal barrier coatings, and provide you with the highest quality products available.

thermacote image gallery

thermacote case studies

coatings news

Ratings

Green Coatings from a Global Perspective

This article examines the different restrictions and indicators currently used to classify coatings as “green.” It also takes a look at organizations and governmental agencies involved in the classification of these coatings and discusses the processes involved. Finally, it proposes guidelines for the development of a universal standard based on existing commonality that would then have to be accepted by the global sanctioning bodies and users, while overcoming the bureaucratic hurdles and other obstacles and challenges in the way.

READ MORE >
